The WELDMART CUT-100 is a high-performance plasma cutting machine built for precision and ease of use. It features high-frequency arc starting for quick, contactless starts and delivers clean, smooth cuts with minimal finishing required. With both self-locking and non-self-locking modes, it offers flexibility for different cutting tasks. Powered by advanced IGBT inverter technology, it ensures stable current output, making it a reliable tool for heavy-duty and professional metal cutting jobs.
FEATURES:
TECHNICAL PARAMETERS:
Model | CUT 100 |
Input voltage | 3 phase 415V±15% |
Rated input capacity | 28KVA |
Duty Cycle | 60% |
Current Adjust Range | 20-100A |
Output Non-load Voltage | 320V |
Rated load voltage | 120V |
Power Factor | 0.95 |
The cutting gun uses air pressure | 0.45 |
Max Cutting Thickness | 35mm |
Cutting gas flow rate | 250 |
Shell Protection Grade | IP21S |
Dimension | 595x306x530mm |
Weight | 33.6Kg |
