CUT 120

CUT 120

The WELDMART CUT 120 with inbuilt air compressor offers adjustable cutting current from 20A to 120A, making it perfect for cutting various metals like carbon steel, stainless steel, galvanized steel, copper, and aluminium. Compatible with CNC systems, it delivers precise, clean cuts with smooth edges. Ideal for both manual and automated cutting tasks in workshops and fabrication industries.

FEATURES:

  • CNC System Compatibility:
    Seamlessly integrates with CNC systems for precise, automated cutting operations.
  • Adjustable Cutting Current (20A to Max Output):
    Machine allows current adjustment to suit different materials and thicknesses.
  • Clean and Smooth Cuts:
    Delivers high-quality cuts with minimal dross, reducing post-processing time.
  • Stable and Efficient Power Output:
    Ensures consistent cutting performance for both manual and CNC-controlled
    operations.
  • Built-in Air Compressor:
    No external air supply needed – fully self-contained for convenience.

TECHNICAL PARAMETERS:

Model
CUT 120 inbuilt air compressor
Input voltage
3 ph 415V
Rated input capacity
39KVA
Rated non-load voltage
300V
Power factor
0.95
Current adjust range
30-120A
Max cutting thickness
40mm
Duty cycle
60%
Insulation Class
F
Shell protection grade
IP21 S
Dimension
640x320x640mm
Weight
55kg
