The GALAXY 400T G is a multi-process, three-phase power source with separate wire feeder. It features a MIG/MAG pulse mode for very precise welding energy control, reducing deformation of the workpieces being welded. Pulse synergy increases welding speeds and reduces spatter, while improving the aesthetics of the weld bead. Excellent for welding thin aluminium and stainless steel, the GALAXY 400T G, equipped with its separate WF 36 wire feeder, is the modern workshop solution for smooth, touch-up-free welds.

MULTI-PROCESS

• MIG/MAG Pulse:
  – steel and stainless steel wire: Ø 0.6 to 1.2 mm
  – aluminium wire: Ø 0.8 to 1.2 mm
  – Flux-cored wire (inverted polarity): Ø 0.9 to 1.6 mm
• MMA DC / Pulse: basic and rutile electrodes
• TIG DC Lift / Pulse

PREMIUM MIG/MAG WELDING

• 4 welding modes:
  – Standard: ideal for fast, simple welding applications
  – Pulse: reduces spatter and touch-ups in all welding positions
  – ModulArc: ideal for assembling aluminium alloys that require aesthetic appeal
  – Manual: suitable for experienced welders and DMOS welding
• Digital arc control with instant ignition and no cratering at the end of the bead
• Pulse arc achieves up to 30% higher welding speeds
• 4-roller motorised wire feeder with digital encoder for precision wire feed

INTELLIGENT

• +40 synergies for various materials: Steel, AlMg, AlSi, CrNi, CuSi
• New intuitive, multilingual 3.5’’ HMI
• Full machine and synergy updates via USB stick
• Job memory of up to 200 welding programs for recurring applications
• Portability function: user JOBS and machine configuration can be loaded/saved/transported
  from a USB stick
• Traceability of all weld beads to EN 3834
• Calibration mode for welding accessories in order to adjust the displayed voltage
• User mode for sharing the product with several users
• Free online tool for customising the interface

ERGONOMIC

• Dual displays for easier setting adjustments if the wire feeder is suspended and
  inaccessible
• Reinforced wheels for stability and manoeuvrability
• Cable connection at the rear of the power source, no tools required
• 4 lifting points for easy suspension and safe transport
• Lowered gas bottle support for easy loading (10 m3 max)
• IP23S rated to operate in difficult environments
• Large storage compartment
