STANDARD REFERENCE RADIOGRAPH SET

16 Radiographs

20 Total Discontinues and 6 Processing Defects

• Document Package Only: Certificate of Conformance, CAD Drawings, Test Sheets and Radiographs
• Film Set Contains: 16 Radiographs of 20 flaws and 6 Processing Defects
• Radiographs are of 10 carbon steel specimens as follows:
  • (4) Plates: 0.375″T
  • (3) Plates: 0.625″T
  • (1) Tee: 0.375″T
  • (2) Pipe:  4″ Sch80 (0.337″ wall
